Filestor – Base Mounted Track System
Rigid metal base features platform and adjustable feet for accurate levelling on uneven floors
- Large 0.5 tonne wheels allow easy movement
- Anti-tilt Mechanism prevents tipping
- Available with Hand Operation or Mechanically Assisted
- Timber particle board infill flooring
Configurations are endless – Ask us for a measure and quote today – We work to maximise your given space
| Accessories: | Wire filing racks, Roll out work shelves, Pull out filing frame, Magnetic label holders, Back cross bracing, Bin fronts, Solid dividers | |
| Colours: | Standard Silver Grey or White – other Powdercoat colours available on request | |
| Bay Heights: | 1875, 2175, 2375 mm – Add 75-115mm for installed Height | |
| Shelf Depths: | 250, 300, 400, 450, 500, 600 mm – Add 25mm for installed Depth | |
| Bay Widths: | 750, 900, 1050, 1200 mm | |
| Tandem Widths: (Combination of sizes available) |
750 + 750 = 1500mm 900 + 900 = 1800mm 900 + 1200 =2100mm 1200 + 1200 = 2400mm |
|
| Track length can be made to any size to maximise capacity in any room. | ||
| Standard Unit Lengths – based on 400mm deep bays: | ||
| 4 Bay Unit: | 2,560mm with 800mm aisle | |
| 6 Bay Unit: | 3,350mm with 800mm aisle | |
| 8 Bay Unit: | 4,160mm with 760mm aisle | |
| 10 Bay Unit: | 5,000mm with 750mm aisle | |
| Access Aisles: | Minimum aisle width is 650mm | |
